Stiltz Trio+ is a free-standing, self-supporting lift with no visible hoist and no noisy motor. It offers quiet travel, fast installation, and is designed for larger spaces, including wheelchair access.
Why choose this product?
Unique Selling Proposition (USP)
Wheelchair Accessible
Designed for larger spaces and includes features like wide entry/exit and a gently-angled ramp for easy wheelchair access.
Free-Standing Design
No visible hoistway or noisy motor, offering flexible placement within the home.
Quick Installation
Modular sections allow for standard installation in just one day.
Economical Operation
Plugs into a standard domestic power socket, similar to any household appliance.
Self-Contained Drive System
Drive system is housed within the lift, eliminating the need for external power packs.
Powered Door Option
Available with a powered door for convenient entry and exit.
Technical Specifications
- Lift Type: Domestic personal homelift that complies with the Machinery Directive 2006/42/EC. In addition, the EN81 range was built, developed and operated in accordance with BS EN81-41:2010.
- Standard Colour: Grey (RAL 7038)
- Load Capacity: Max. 250kg / 2-3 people or a full-sized wheelchair.
- Illumination: Contemporary ambient lighting with high-quality LED strips.
- Drive: Self contained rope drum, braked gear motor drive. Enclosed within the lift car roof space.
- Electricity: 220V – 240V, 10A – 20A socket – Plugs into a standard domestic power socket.
- Control: Lift is controlled via the control panel and two remote controls. Additional remote controls are available.
- Entrance: Single door or ThruCar configuration. Level access with integral ramp available on all door options.
- Speed: Nominal speed: 100mm / sec. Max speed: 150mm / sec.
- Travel Limit: Up to three floors. With a maximum of 6000mm of travel.
- Lift Car Door: 1100mm hinged half-height door or full-height door options available as standard. LED light curtain will protect the upper half of the car regardless of door height.
- Dimensions: 1941mm - Max. internal car height, 2395mm - Max. external lift height, 1241mm x 967mm - Max. lift car footprint, 1147mm x 773mm - Internal car footprint, 1280mm x 1070mm - Floor cut-out, 800mm - Lift entrance width.
- Height Limit: 2240mm - Min. upper floor ceiling height, 2440mm - Max. upper floor ceiling height, for maximum car height.
- Fire Seal: Fire seal option available.
- Footprint: 1.25m²
Frequently Asked Questions (FAQ)
Can Stiltz lifts be installed without a pit?
Yes, Stiltz Duo+ and Trio+ require minimal structural modifications and no pit.”
Are Stiltz lifts suitable for wheelchair users?
Yes, Trio+ is designed to accommodate wheelchairs with its wider entry and exit points.
How long does it take to install a Stiltz lift?
Stiltz lifts are made up of modular sections, and standard installations typically take just one day.
Can I install a Stiltz lift in an existing home?
Yes, Stiltz lifts require no construction apart from a flat surface, making them ideal for existing homes.
Does the Stiltz Trio+ require a machine room?
No, Stiltz Trio + has a self-contained drive system housed at the top of the lift, eliminating the need for external power packs.
What is the difference between Duo+ and Trio+?
Duo+ supports 2 people (170 kg), while Trio+ supports 3 people or a wheelchair (250 kg) and offers wider entry/exit points for accessibility.”
Does the Stiltz Trio+ require a machine room or external power packs?
No, the Stiltz Trio + has a self-contained drive system housed at the top of the lift, eliminating the need for external power packs or a machine room.
Is the Stiltz Trio + noisy during operation?
No, the Stiltz Trio + is powered by a quiet electric self-contained motor and has no noisy hydraulics, ensuring quiet travel.
How long does it take to install a Stiltz Trio+?
The Stiltz Trio+ is made up of modular sections, and standard installations typically take just one day.
